Pulse Clean Flat Panel Pleated Filter Cartridge Wide Fold Design With Big Filtering Area

Name: Pulse Clean Flat Panel Pleated Filter Cartridge Wide Fold Design With Big Filtering Area
Brand: Austin Filter
Price: 1 USD

Buy cheap Pulse Clean Flat Panel Pleated Filter Cartridge Wide Fold Design With Big Filtering Area product

Brand Name : Austin Filter

Model Number : 500 x 1000mm

Certification : ISO 9001

Place of Origin : Made in China

MOQ : 10 sets

Price : negotiable

Payment Terms : L/C, T/T

Supply Ability : 200 pcs per day

Delivery Time : 10 working days

Packaging Details : Export box

Name : Flat Type High Flow Panel Filter Cartridge 500 mm Flange

Filter media : Polyester

Work efficiency : 99.99%

Work temp : 80-130 degree C

Construction : Pleated

Package : pallet

Contact Now

Pulse Clean Flat Panel Air Pleated Filter elements

Performance Description of Flat Filter Element

Flat filter element makes it possible to design small compact filter system and still get the optimal

air filtration. Air filtration can be further optimized by selecting the right filter media for your specific

dust type. We have a number of quality filter media to ensure maximum options when it comes to

removing your particular dust type.

Item	Description	Data
1	Weight(g/m2)	240
2	Thickness(mm)	0.6
3	Porosity(S.l/m2)	180
4	Filtration efficiency %	99.99%
5	Filtration precision	0.1-5 micron
6	Working temp.	130 degree
7	Filter pressure	0.5Mpa

Features:

1. Unique PU or plastic coating anti-rust caps and metal frame

2. Wide pleat spacing,easy-cleaning design

3. Unique rotation glue,effectively separate the pleats,protect the filter media from abrasion by inner liner

4. Specific gasket

5. Top open, bottom open/bottom close with deflating bolt hole

Pulse Clean Flat Panel Pleated Filter Cartridge Wide Fold Design With Big Filtering Area
